Futaba T7XC 7-Channel Surface Radio (Tx Only)

FEATURES

• Full colour touch screen LCD.
• T-FHSS SR (Super Response) T-FHSS (Telemetry).
• Updatable software (via microSD card).
• 40 model memories.
• NFC Communication.
• Integral Type Dial switch.
• Brake mixing for large cars.
• Steering Mix.
• 4 wheel steer mixing.
• Dual ESC mixing.
• Gyro mixing.
• Tank mixing.
• CPS mixing.
• S.Bus servo settings.
• Futaba MC-Link.
• Throttle speed.
• Steering speed.
• Non-telemetry LED.
• Dial select function.
• Trim / dial lock functions.
• Vibration alarm built into the grip.

CONTENTS

• 1x T7XC transmitter.
• 1x AA dry battery holder.
• 1x Mini screwdriver.
• 1x Ratchet plate.
• 1x Instruction manual.

DETAILS

The T7XC was developed for car/boat modellers who want a premium stick style radio for land vehicles and water craft. The updated software is based on the well known T7PX with some new features and, to house it all, a stylish ergonomic case. The latter, as you'll doubtless have clocked, is made from high quality moulded plastic and finished in a stunning deep satin black with chrome accents and switches. The huge 4.3" colour touch screen has a 'transflective' surface for superb visibility indoors and out and responds quickly to the touch. Meanwhile a conventional jog dial is provided if you prefer to navigate that way.

Using Futaba's most recent T-FHSS SR transmission mode, the radio boasts an ultra-fast frame rate of 2.45 milliseconds! This new system brings a locked in feel and response that racers and performance drivers will truly appreciate. The T7XC is also compatible with Futaba T-FHSS, S-FHSS and FASST so you can select the preferred transmission system for each car to suit your requirements and budget. With T-FHSS telemetry, data can be displayed on the screen or relayed by a synthesized voice using the in-built speakers or your own headphones.

The T7XC has the ability to update its software using an SD card but it also has NFC (Near Field Communication) which allows you to update the radio from an android phone just by opening an APP and placing the transmitter alongside!

Compatible Receivers:
T-FHSS SR/T-FHSS (Default) - R334SBS/ R334SBS-E
T-FHSS - R304SB/ R304SBE
S-FHSS - R2104GF/ R204GF-E/ R2008SB/ R2006GS
FASST - R614FS/ R614FF-E/ R604FS/ R604FS-E
Note: R3008SB & T-FHSS Air system receivers do not operate.

Servos Compatible with SR Mode:
The following servos are compatible with Futaba's ultra fast T-FHSS SR transmission system.
BLS371SV, BLS471SV, BLS571SV, BLS671SV, S9372SV, S9373SV, BLS373SV

Specs:
Model Memory: 40
NFC: Yes
Screen: 109mm (4.3") Backlit Colour TFT
Transmission Power: 100mW EIRP
LiPo: FT2F1700BV2 (Req.)
NiCad/Ni-MH: NT5F1800B (Req.)
Modulation: T-FHSS Surface, T-FHSS SR, S-FHSS, FASST
Receiver: Futaba R334SBS (Inc.)
Switches: 6
Trims: 5
Dials: 2
Channels: 7
